Spesifikasi
| Nomor Seri | 6” (152.4 mm) Pole Mount Bolt Down Kit – E047458 12” (304.8 mm) Pole Mount Bolt Down Kit – E047663 18” (457.2 mm) Pole Mount Bolt Down Kit – E047864 Pole Mount Floor Stand – E048069 Pole Mount Tabletop Stand – E160104 Rear-facing Display Pole Mount Kit – E038989 |
| Varian Enclosure | Black/Silver |
| Kompatibilitas | E047458, E047663, E047864, E048069: 1002L, 1302L, 1502L, 1502LM, 1902L, 1903LM, 2002L, 2202L, 2203LM, Android I-Series 2/3/4 (10”, 15”, 22”), Windows I-Series 2.0 (15”)* E160104: 0702L, 1002L, Android I-Series 2/3/4 (10”) E038989: 0702L, 1002L, 1302L, Android I-Series 2/3/4 (10”) *M4x17 mounting screws are recommended when pairing with Windows I-Series 2.0 (15”) |
| Opsi Pemasangan | E047458, E047663, E047864, E048069, E160104: 75 x 75mm and 100 x 100mm E038989: 75 x 75mm |
| Dimensi | E047458: 6.4″ x 6.4″ x 9.8″ / 163.5 mm x 163.5 mm x 249.5 mm E047663: 6.4″ x 6.4″ x 15.7″ / 163.5 mm x 163.5 mm x 399.5 mm E047864: 6.4″ x 6.4″ x 21.0″ / 163.5 mm x 163.5 mm x 534.5 mm E048069: 21.7″ x 13.8″ x 42.0″ / 550 mm x 350 mm x 1066.5 mm E160104: 7.1″ x 7.1″ x 6.8″ / 180 mm x 180 mm x 172.5 mm E038989: 8.3″ x 4.8″ x 10.0″ / 210 mm x 122 mm x 253.4 mm |
| Dimensi Box Pengiriman | E047458: 13.7″ x 10.2″ x 9.6″ / 348 mm x 258 mm x 245 mm E047663: 19.6″ x 10.2″ x 9.6″ / 498 mm x 258 mm x 245 mm E047864: 24.6″ x 10.4″ x 9.1″ / 625 mm x 265 mm x 230 mm E048069: 44.9″ x 18.5″ x 10.0″ / 1140 mm x 470 mm x 255 mm E160104: 11.22″ x 11.02″ x 9.25″ / 285 mm x 280 mm x 235 mm E038989: 11.8” x 9.8″ x 7.9″ / 300 mm x 250 mm x 200 mm |
| Berat (Sebelum Dikemas) | E047458: 2.5 lbs / 1.14 kg E047663: 3.1 lbs / 1.4 kg E047864: 3.5 lbs / 1.6 kg E048069: 33.1 lbs / 15 kg E160104: 5.29 lbs / 2.4 kg E038989: 2.4 lbs / 1.1 kg |
| Berat (Setelah) | E047458: 4.1 lbs / 1.87 kg E047663: 5.1 lbs / 2.3 kg E047864: 5.8 lbs / 2.64 kg E048069: 38.4 lbs / 17.4 kg E160104: 6.2 lbs / 2.81 kg E038989: 3.3 lbs / 1.49 kg |
| Garansi | 2-year |
| Paket Sudah Termasuk | E047458, E047663, E047864: Stand, 100mm VESA plate, QIG, 4x M4x6 pan-head screws, 4x M4x8 pan-head screws, 4x M4x12 pan-head screws E048069: Stand, 75mm VESA plate, Installation Flyer, 4x M4x6 pan-head screws, 4x M4x8 pan-head screws, 4x M4x12 pan-head screws E160104: Stand, 100mm VESA plate, 4x M4x 6 Pan-Head screws, 4x M4x8 pan-head screws E038989: Stand, VGA cable, USB cable, USB Y cable, QIG, 4x M4x6 pan-head screws, 4x M4x8 pan-head screws |
