Features & Benefits
Integrated touch.
The 15-inch touchscreen monitor features AccuTouch® five-wire resistive and IntelliTouch® surface acoustic wave (SAW) with an anti-glare display and Dual/Serial USB ready for any retail or hospitality environment.
MSR ready.
The optional ergonomic three-track mag stripe reader (MSR), is easily installed providing an elegant, integrated solution. The MSR is available in two versions: USB with keyboard emulation; and USB with human interface device (HID) class specification 1.1
Flexible mounting.
The Elo 1515L offers multiple mounting options to ensure installation flexibility including: wall- and pole-mount via standard VESA mount patterns as well as tabletop accommodations with the use of the desktop stand.
Commercial grade.
The 15-inch touchscreen monitor delivers the quality and reliability Elo is known for and is backed by our three-year standard warranty. All of our products go through rigorous reliability testing (over 20 tests) to deliver 50,000 MTBF.
Other features.
Economical and reliable
Up to 1024 x 768 resolution at 75 Hz
Dual serial/USB interface
Mounting holes on stand bottom for tabletop security
Both Internal power and optional external 12VDC power supply
Three-year standard warranty
Energy-saving LED backlights
Touchscreen sealed against dirt, dust and liquids
Removable stand and VESA mounting option
Digital on-screen display (OSD)
Worldwide agency approvals
Specifications
| Part Number(s) | IntelliTouch (Worldwide) – E700813 IntelliTouch (EMEA) – E399324 AccuTouch (Worldwide) – E210772 AccuTouch (EMEA) – E344320 |
| Enclosure Color | Dark Gray |
| Touch Technology & Capacity | 5-Wire Resistive (AccuTouch®) – Single-Touch SAW (IntelliTouch® Surface Acoustic Wave) – Single Touch |
| Diagonal Size | 15” diagonal, Active matrix TFT LCD (LED) |
| Aspect Ratio | 4:3 |
| Active Area | 12.0″ x 9.0″ / 304mm x 228mm |
| Resolution | 1024 x 768 |
| Other Supported Resolutions | 640 x 350 70 Hz 640 x 480 60, 72, 75 Hz 640 x 480 66 Hz 720 x 400 at 70 Hz 800 x 600 at 56, 60, 72 or 75 Hz 832 x 624 at 75 Hz 1024 x 768 65 Hz 1024 x 768 60, 70, 75 Hz |
| Viewing Angle | Horizontal: ± 80° or 160° total / Vertical: 70°/80° or 150° total |
| Number of Colors | 16.2 million |
| Brightness (typical) | LCD panel: 250 nits AccuTouch: 200 nits IntelliTouch: 225 nits |
| Response Time-total (typical) | 8 msec |
| Contrast Ratio | 800:1 |
| Input Video Format | Analog VGA on Female DB-15 connector |
| Input Video Frequency | Horizontal: 31.5-60.2 kHz / Vertical: 56.3-75 Hz |
| Power | Internal AC, power cable-C5 type Adapter input voltage range: 100-240VAC, 50/60Hz Monitor input power connector: Coaxial power jack (2.0mm (+0.0 -0.1mm) pin outer diameter, 6.4mm (+/- 0.3mm) barrel inner diameter, 8.8mm (+/- 0.3mm) Barrel depth) Monitor input voltage range: 12VDC +/- 5% |
| Power Consumption (Typical) | AC in, monitor only ON: 9.52 W SLEEP: 1.34 W OFF: 0.30 W |
| I/O Ports | VGA DC jack AC jack USB Type B RS232 (DB9 connector) |
| On Screen Display | Accessible through switches along the bottom. Controls: Menu, Power, Up, Down, Select Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, Volume, Mute, Recall Defaults, Audio Select, Power LED ON/OFF Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese, Korean, Russian Lockouts: OSD, Power |
| Monitor Dimensions (without Stand) | 11.0″ x 13.8″ x 2.2″ / 280 mm x 350 mm x 55 mm |
| Monitor Dimensions (with Stand) | 12.2″ x 13.8″ x 6.9″ / 310 mm x 350 mm x 175 mm |
| Shipping Box Dimensions | 10.2″ x 17.5″ x 15.0″ / 260 mm x 445 mm x 380 mm |
| Weight (with stand) | 10.6 lb / 4.8 kg |
| Shipping Weight (With stand) | 15.4 lb / 7.0 kg |
| Operating Temperature | 0°C to 40°C / 32°F to 104°F |
| Storage Temperature | -20°C to 60°C / -4°F to 140°F |
| Humidity | Operating: 20% to 80%; Storage: 10% to 90% |
| MTBF | 50,000 hours demonstrated |
| Mounting Options | VESA 4-hole 75mm mounting interface on rear of unit |
| Warranty | 3-year |
| Extended Service Options | 4 year warranty coverage – Elo P/N: E898247 5 year warranty coverage – Elo P/N: E898449 3 year warranty coverage + AUR – Elo P/N: E898648 4 year warranty coverage + AUR – Elo P/N: E894921 5 year warranty coverage + AUR – Elo P/N: E895125 |
| Regulatory approvals and declarations | Canada CUL, IC China CCC Europe CE United Kingdom UKCA Korea KCC Taiwan BSMI United States FCC, UL Japan VCCI International CB Australia RCM Russia EAC Mexico CoC India BIS RoHS, China RoHS, WEEE, REACH |
| What’s in the Box | Touch monitor Quick Install Guide 3x Tie wraps VGA cable Touch USB cable NA Power cable EU Power cable (For E344320/E399324 only) EEI Label |
| Optional Peripherals | North America power adapter and cable kit – Elo P/N: E005277 European & Korea power adapter and cable kit – Elo P/N: E571601 UK power adapter and cable kit – Elo P/N: E180092 China power adapter and cable kit – Elo P/N: E558862 Taiwan power adapter and cable kit – Elo P/N: E818655 Japan power adapter and cable kit – Elo P/N: E182546 Argentina power adapter and cable kit – Elo P/N: E887099 Australia power adapter and cable kit – Elo P/N: E637593 |
