Overview
Elo Backpack® Linux PC
Enterprise Linux in a box
Features & Benefits
Experience the Elo approach to Linux
With decades of development and customizations made to support global enterprise customers, Elo’s Linux-based platform offers Linux device drivers, uniform SDKs, a constantly growing set of tools and an expansive lineup across sizes and form factors.
Built for any use
From digital signage and self-service kiosks to point of sale, kitchen display systems (KDS) and automation controls, the Elo Backpack Linux PC offers the connectivity, performance and durability to power almost any application.
Small footprint
Purpose-built to accommodate compact spaces, the Elo Backpack Linux device offers a small footprint in both size and weight.
Universal VESA mount
Easily secure the Elo Backpack Linux PC to any counter or in a kiosk with the built-in 75mm or 100mm VESA mount.
Commercial-grade performance
Equipped with Rockchip 6-core processor and your choice of Debian 10 distributions or newer, the Elo Backpack Linux PC delivers the performance your business needs.
Connect it all
The Elo Backpack Linux device offers 4x USB 3.0, Ethernet, Bluetooth, Wi-Fi, HDMI, USB-C output, micro-SD, GPIO and Wi-Fi antennas.
Your Backpack
Your solution
From 7-65 inch, the Backpack adds a powerful Linux OS to Elo touchscreen monitors, open frames and large format interactive displays.
Get peace of mind with EloCare℠
From advance unit replacement to accidental damage protection, EloCare delivers service and support from the people who know your Elo products best.
- Advance Unit Replacement
- Extended Warranty
- Professional Services
Specifications
| Part Number(s) | E143585 |
| Enclosure Color | Black |
| Processor | Rockchip RK3399 |
| Memory (RAM) | 4GB LPDDR4 |
| Storage | 32GB |
| Wireless | 802.11a/b/g/n/ac + Bluetooth 5.0 Via external antenna |
| I/O Ports | HDMI 4x USB 3.0 support USB-C output Micro SD slot GPIO Ethernet 1x LAN (Gigabit) DC in |
| OS | Linux Debian 10 |
| Resolution | USB-C: 3840 x 2160 @60fps HDMI: 3840 x 2160 @60fps |
| Power Supply | AC input voltage: 100-240 VAC Input frequency: 50-60 Hzpower adapter (included in accessory box) |
| Power Consumption (Typical) | On: 3.7W Off: 0.28W Sleep: 3.18W |
| Mounting Options | VESA 75mm and 100mm |
| Dimensions | 4.5″ x 5.5″ x 1.0″ / 114 mm x 139 mm x 25.4 mm |
| Shipping Box Dimensions | Individual System: 14.6″ x 8.2″ x 2.4″ / 371 mm x 208 mm x 62 mm 8 systems/carton: 17.4″ x 10.6″ x 16.3″ / 441 mm x 270 mm x 413 mm |
| Weight (Unpackaged) | 0.82 lbs / 0.37 kg |
| Weight (Packaged) | Individual System: 0.82 lbs / 0.37 kg 8 systems/carton: 22.38 lbs / 10.15 kg |
| Operating Temperature | 0°C to 40°C / 32°F to 104°F |
| Storage Temperature | -20°C to 50°C / -4°F to 122°F |
| Humidity | Operating: 20% to 80% Storage: 10% to 95% |
| Real-Time Clock | lithium coin cell battery |
| MTBF | 50,000 hours demonstrated |
| What’s in the Box | Backpack 4 North American Power Cable European Power Cable 1x Power Brick with locking screw 2x Antenna Quick Install Guide |
| Regulatory approvals and declarations | UL/cUL (US) FCC (US) IC (Canada) CE (Europe) CB (International) VCCI, MIC (Japan) RCM (Australia) |
| Warranty | 2-year |
| Extended Service Options | 3 year warranty coverage – Elo P/N: E895914 4 year warranty coverage – Elo P/N: E896120 5 year warranty coverage – Elo P/N: E896322 2 year warranty coverage + AUR – Elo P/N: E896513 3 year warranty coverage + AUR – Elo P/N: E896699 4 year warranty coverage + AUR – Elo P/N: E896903 5 year warranty coverage + AUR – Elo P/N: E897104 |
